Results (5)


Electron beam lithography and pattern transfer on membrane grids for transmission electron microscopy

We describe a fabrication process for electron beam lithography (EBL) and the following pattern transfer steps on transmission electron microscope (TEM) grids. For demonstration purposes, we use commercial off-the-shelf TEM grids consisting of a thin suspended silicon nitride membrane on a silicon frame supporting substrate. For the pattern transfer, we demonstrate both an additive patterning technique with metal deposition and lift-off, and a subtractive patterning technique with reactive ion etching. This process could enable direct ...

Version
Version 1.1
Date
2 weeks, 5 days ago
Lab
EPFL - LPQM
Comments
0
Viewed
123
Downloads
35
Liked
3


Efficient removal of ZEP ebeam resist after dry etching

Resist removal is an essential step for multi-layer lithography processes where a clean and contamination-free surface is essential to avoid shadow etching patterns from resist leftovers. We show that a short \mathrm{O_2} plasma exposure followed by a full NMP solution cycle removes the resist fully and leaves the surface contamination free.

Version
Version 1.0
Date
3 months, 2 weeks ago
Lab
EPFL - LPQM
Comments
0
Viewed
1109
Downloads
245
Liked
3

Fabrication of patterned silicon nitride nanomembranes at the LKB

Thin silicon nitride nanomembranes are attracting growing attention following a novel fabrication method which consists in patterning them with a phononic crystal. In engineering the vibrational mode profile, the dominant mechanisms of loss, radiation loss and intrinsic material loss, are simultaneously addressed and mitigated. The fabrication method employed by the optomechanics group at the Laboratoire Kastler Brossel is here presented, only employing basic lithography techniques and wet etching processes.

Version
Version 1.1
Date
1 year ago
Lab
Sorbonne - Kastler-Brossel
Comments
0
Viewed
2152
Downloads
536
Liked
3

Bulk and Sleeve Electron Beam Lithography for Silicon Nitride Photonic Crystals

This is a method to improve the quality of lithography - in particular electron beam lithography (EBL). During an EBL exposure the electrons undergo different scattering processes. One scattering process that plays an important role is the back scattering of the electrons from the substrate or different stacks of thin film present in the exposure stack. As a result the actual dose that the resist sees is quite different that the original exposure dose. This ...

Version
Version 1.0
Date
1 year, 4 months ago
Lab
EPFL - LPQM
Comments
0
Viewed
1424
Downloads
537
Liked
1
