On the fabrication of high-surface-area and high-aspect-ratio gold nanostructures

We highlight some stability issues in high-surface-area and high-aspect ratio gold nanostructures fabricated using inorganic adhesion layers on silica substrates. We ascribe these problems to capillary and surface effects and show the use of organic silane self-assembled monolayers to improve the long-term stability of such structures.

Version
Version 1.1
Date
8 months ago
Lab
EPFL - NAM
Comments
0
Viewed
543
Downloads
180
Liked
2

Electron beam lithography and pattern transfer on membrane grids for transmission electron microscopy

We describe a fabrication process for electron beam lithography (EBL) and the following pattern transfer steps on transmission electron microscope (TEM) grids. For demonstration purposes, we use commercial off-the-shelf TEM grids consisting of a thin suspended silicon nitride membrane on a silicon frame supporting substrate. For the pattern transfer, we demonstrate both an additive patterning technique with metal deposition and lift-off, and a subtractive patterning technique with reactive ion etching. This process could enable direct ...

Version
Version 1.1
Date
10 months, 2 weeks ago
Lab
EPFL - LPQM
Comments
0
Viewed
739
Downloads
208
Liked
3

Efficient removal of ZEP ebeam resist after dry etching

Resist removal is an essential step for multi-layer lithography processes where a clean and contamination-free surface is essential to avoid shadow etching patterns from resist leftovers. We show that a short \mathrm{O_2} plasma exposure followed by a full NMP solution cycle removes the resist fully and leaves the surface contamination free.

Version
Version 1.0
Date
1 year, 1 month ago
Lab
EPFL - LPQM
Comments
0
Viewed
1607
Downloads
494
Liked
3

Monolithically integrated InGaAs microdisks on Si for nanophotonics

This work was presented at the Nanofabrication Photonics Online Meetup, 16-18 May 2021. Template-assisted selective epitaxy enables the local integration of group III-V semiconductors on Si with high material quality for nanophotonic applications. Here we demonstrate evidence of room temperature lasing at 1530 nm for a monolithically integrated InGaAs whispering gallery mode cavity on Si with a thickness of 300 nm and a diameter of 1.5 µm. These devices can potentially be scaled down further ...

Version
Version 1.0
Date
1 year, 2 months ago
Lab
IBM Research Zurich - Materials Integration and Nanoscale Devices
Comments
0
Viewed
1112
Downloads
370
Liked
3

Fabrication of patterned silicon nitride nanomembranes at the LKB

Thin silicon nitride nanomembranes are attracting growing attention following a novel fabrication method which consists in patterning them with a phononic crystal. In engineering the vibrational mode profile, the dominant mechanisms of loss, radiation loss and intrinsic material loss, are simultaneously addressed and mitigated. The fabrication method employed by the optomechanics group at the Laboratoire Kastler Brossel is here presented, only employing basic lithography techniques and wet etching processes.

Version
Version 1.1
Date
1 year, 9 months ago
Lab
Sorbonne - Kastler-Brossel
Comments
0
Viewed
2404
Downloads
695
Liked
3
